Castle Care Tech 8 Zone LITE Expander

The ZEM8 allows 8 zone expansion of Pyronix security control panels.



Key Features

  • RS485 Expander
  • 8 Double Pole or Double EoL Inputs
  • In polycarbonate box with window



Technical Specification

Plastic housingYes
Tamper protectionCase tamper
Wired EOL inputs8
Wired double pole inputs8
Total inputs8
Outputs on board4
Certified operating temperature-10C to +40C
Nominal operating temperature-10C to +40C
Physical dimensions (H x W x D)173 x 126 x 31mm
Weight260g
Operating voltage10.5V to 15V DC
Quiescent current consumption40mA
Security GradeGrade 3
Environmental classII
EN CertificateEN50131-1:2006 | PD6662:2010
Certification typeSelf-certified
Electrical conformityCE
Warranty2 years
  • Model: EURO-ZEM8
  • Shipping Weight: 1 kgs
  • Manufactured by: Castle Care-Tech
Ask a Question

£44.40 Ex VAT
