Siemens MAGIC Dual 18m Wide Angle Detector

Name: Siemens MAGIC Dual 18m Wide Angle Detector
Brand: Siemens/Vanderbilt
SKU: PDM-I18
Price: 24.23 GBP
Availability: InStock

(image for) Siemens MAGIC Dual 18m Wide Angle Detector

larger image

MAGIC motion detector PDM-I18 is impressive with its modern and elegant design. Its style is suitable for all installation situations. Together with the enhanced Visatec algorithm, its patented MAGIC mirror provides reliable detection of intruders and the highest false alarm immunity. Flexible installations can be carried out quickly and error-free due to features like Auto Walktest and new End-of-Line concept (EoL).

Technical Specification

Detection characteristics / range	volumetric / 18 m
Optical system	MAGIC mirror
Approval	EN50131-2-2 Grade 2 VdS Class B
Pet immunity	no
Supply voltage	9 ... 16VDC (12V nom.)
Current consumption	2.5mA (rms) 4.7mA (max. peak)
Sensitivity evaluation mode	4 settings
Outputs	30VDC / 100mA, NC
Walk test input	LOW ≤ 1.5V / HIGH ≥ 3.5V
Set/unset input	LOW ≤ 1.5V / HIGH ≥ 3.5V
Walking speed	0.2 ... 3m/s
EOL resistor	RI = 4.7kΩ ±5%, 250mW REoL = 4.7kΩ ±5%, 250mW
Operating temperature	-10°C …+55°C
Air humidity (EN 60721)	< 85% RH, non-condensing
Storage temperature	-20°C …+60°C
Housing protection (EN 60529)	IP41 / IK02
Dimensions (W x H x D)	64mm x 147mm x 35mm
Weight	0.115kg
Colour	RAL9003
