Siemens MAGIC 12m Wide Angle PIR Detector

Name: Siemens MAGIC 12m Wide Angle PIR Detector
Brand: Siemens/Vanderbilt
SKU: PDM-I12
Price: 27.8 GBP
Availability: InStock

(image for) Siemens MAGIC 12m Wide Angle PIR Detector

larger image

MAGIC motion detector PDM-I12 is impressive with its thin and flat design. Its style is suitable for all installation situations. Together with the enhanced Visatec algorithm, its patented MAGIC mirror provides reliable detection of intruders and the highest false alarm immunity. Flexible installations can be carried out quickly and error-free due to features like Auto Walktest and new End-of-Line concept (EoL).

Technical Specification

Detection characteristics / range	volumetric / 12m
Optical system	MAGIC mirror
Approval	EN50131-2-2 grade 2 VdS Klasse B
Pet immunity	yes (option)
Supply voltage	9 ... 16 VDC (12V nom.)
Current consumption	2.5 mA (rms) 4.7 mA (max. peak)
Sensitivity evaluation mode	4 settings
Outputs	30 VDC / 100 mA, NC
Walk test input	Low ≤ 1,5 V / high ≥ 3,5 V
Set/unset input	Low ≤ 1,5 V / high ≥ 3,5 V
Walking speed	0.2 ... 3 m/s
EOL resistor	RI = 4.7 kΩ ±5%, 250 mW REoL = 4.7 kΩ ±5%, 250 mW
Operation temperature	-10°C…+55°C
Air humidity (EN 60721)	< 95% RH, non-condensing
Storage temperature	-20°C…+60°C
Housing protection (EN 60529)	IP41 / IK02
Dimensions (W x H x D)	57mm x 128mm x 32mm
Weight	0.1kg
Colour	RAL9003
