CDVI IEVO Ultimate Fingerprint Reader with Card Reader
The IEVO-U+ by CDVI is a fingerprint reader with high performance multi-spectral imaging sensor and built-in card reader.
The ievo ultimate™ is a fingerprint scanner employing a high performance multi-spectral imaging (MSI) sensor. It reads fingerprints from both the surface and subsurface levels even if they are hard to distinguish due to external factors such as dirt, moisture, and damage.
The fingerprint reader is enabled for 128-bit data transmission and provides highly accurate and quality images to be transferred to the Interface Board. It performs 1:N matching of up to 50,000 fingerprint templates. ievo ultimate™ is designed for external use and remains efficient in harsh weather conditions.
This model comes with a built-in card reader for added flexibility.
Key Features
- Vandal resistant biometric fingerprint reader
- Up to 50,000 fingerprints via Interface Board
- Powerful multi-spectral imaging (MSI)
- ISO PAD Level 1 compliant when spoof detection is enabled
- Built-in card reader for added flexibility
- Optional AES128-bit encrypted data transmission
- Flush or surface mounting kit options
- IP65 rated - suitable for indoor or outdoor installation
Technical Specification
| Technology | MSI sensor, Wiegand |
| Security Level | AES128-bit encryption to Interface Board (on request) |
| User Limit | 10,000 or 50,000 (dependent on Interface Board) |
| Mounting | Surface/Flush |
| Min Temperature (°C) | -20°C |
| Max Temperature (°C) | +70°C |
| Resolution | 500dpi |
| Recommended Mounting Height | 120cm |
| Min. Voltage (V) | 12 Vac/dc |
| Max Voltage (V) | 24 Vac/dc |
| Voltage AC/DC | AC/DC |
| Consumption (mA) | 600mA |
| Wiring Distance | 90m to Interface Board (max), 75m to access control board (max) |
| IP Rating | IP65 |
| IK Rating | IK10 |
| Surface Material | PC/ABS mix |
| Colour | Black or custom RAL colour (on request) |
| Product Height (mm) | 128 mm (surface) |
| Product Width (mm) | 93 mm (flush) |
| Product Depth (mm) | 93 mm (surface), 47 mm (flush) |
