CDVI IEVO Ultimate Fingerprint Reader
The IEVO-U by CDVI is a fingerprint reader employing a high performance multi-spectral imaging (MSI) sensor.
The ievo ultimate™ is a fingerprint scanner employing a high performance multi-spectral imaging (MSI) sensor. It reads fingerprints from both the surface and subsurface levels even if they are hard to distinguish due to external factors such as dirt, moisture, and damage.
The fingerprint reader is enabled for 128-bit data transmission and provides highly accurate and quality images to be transferred to the Interface Board. It performs 1:N matching of up to 50,000 (10,000 standard) fingerprint templates. ievo ultimate™ is designed for external use and remains efficient in harsh weather conditions.
Key Features
- Vandal resistant biometric fingerprint reader
- Up to 50,000 fingerprints via Interface Board
- Powerful multi-spectral imaging (MSI) sensor
- ISO PAD Level 1 compliant (when spoof detection is enabled)
- Optional AES128-bit encrypted data transmission
- Visual and audible feedback
- IP65 rated - suitable for indoor or outdoor installation
- Surface mount as standard or flush mounting kit available
Technical Specification
| Technology | MSI sensor, Wiegand |
| Security Level | AES128-bit encryption to Interface Board (on request) |
| User Limit | 10,000 or 50,000 (dependent on Interface Board) |
| Mounting | Surface (flush mounting kit available) |
| Min Temperature (°C) | -20°C |
| Max Temperature (°C) | +70°C |
| Resolution | 500dpi |
| Recommended Mounting Height | 120cm |
| Min. Voltage (V) | 12 Vac/dc |
| Max Voltage (V) | 24 Vac/dc |
| Voltage AC/DC | AC/DC |
| Consumption (mA) | 600mA |
| Wiring Distance | 90m to Interface Board (max), 75m to access control board (max) |
