Daitem Dual Dwelling Call Point with Keypad and Tag Reader

An outdoor call point from Daitem that is equipped with a badge reader and has an optional keypad. It has a transparent front face so it requires an additional armoured cover (with or without keypad depening on the model you have purchased).

The outdoor call point is fitted with two call buttons for visitors to announce their presence. The badge reader and two buttons on the panel are for the user to open a pedestrian gate or driveway gate. The MHF02X unit comes with a keypad for entering an access code to allow entry.


Key Features

  • Full duplex communication
  • Integrated keypad and badge reader



Technical Specification

Degrees of protectionIP54/IK08
Operating temperature-20 to +70 C
Wiring4 wires required between the panel and the internal unit



  • Model: MHF02X
  • Shipping Weight: 1 kgs
  • Manufactured by: Daitem
Ask a Question

£129.50 Ex VAT
