Siemens Heavy Duty Card and PIN Reader

Name: Siemens Heavy Duty Card and PIN Reader
Brand: Siemens/Vanderbilt
SKU: PP500-EM
Price: 278.99 GBP
Availability: InStock

(image for) Siemens Heavy Duty Card and PIN Reader

larger image

The PP500-EM reads EM4102 cards (also known as Miro or UNIQUE 125 kHz). It has a position indicator light and an illuminated keypad which makes it easy to use in dark places. It also includes a tamper switch for enhanced security.

When BC-Link is used, two of these readers can be installed to control entries and exits using only one door controller. An additional benefit of BC-Link is that it supports online status monitoring.

Technical Specification

System compatibility	SiPass Entro (SiPass integrated only via ACC lite)
Interface to controller	BC-Link, Clock&Data or Wiegand
Card technology	EM4102 (also known as Miro or UNIQUE 125 KHz)
Card compatibility	IB41-EM, IB42-EM, IB44-EM, IB45-EM
Card read distance	Up to 5 cm
Indicators	3 x LED (red/yellow/green) 1 x Buzzer
Keypad	Stainless steel keys 0-9, A, B
Tamper switch	Yes
Operating voltage	12 to 24 VDC
Current consumption	30 mA @ 12 VDC 17 mA @ 24 VDC
Operating temperature	-30 to +50 °C
Environment	Indoor or outdoor use
Housing	Cast metal with stainless steel keys and security lock
Housing protection	IP54
Colour	Grey
Dimensions (W x H x D)	80 x 140 x 40 mm
Weight	1.35 kg
