Videx VX2200 VR digital audio panel

Flush vandal resistant 12 gauge stainless steel audio digital door panel. The VX2200 audio system is based on a 2 wire BUS for audio systems and a 6 wire bus for video systems. Complete with a 2 line 16 character LCD display and voice annunciation for call progressing information. Trade button and code button are also included. Up to 998 apartments can be called from this panel and up to 998 access codes can be stored.


Technical Details

Material - 12 Gauge (2.5mm) 304 grade vertically brushed stainless steel
Panel dimensions - 140mm x 280mm
Bezel outer dimensions - 179mm 316mm
Back box dimensions - 143mm x 283mm x 80mm
Voice annunciation - Yes
Max number of apartments - 1000
Number of buttons - 0-9. Enter, Clear, Code, Trade
Lock output - Dry contact (C, NO & NC) timed (Programmable)
Power - 12Vdc
Systems - VX2200
Push to exit input - Yes
Call reassurance tones - Yes
Coded Access - Yes (Up to 1000 codes up to 6 digits each)
Call progress information - 2 Line back lit LCD display and voice annunciation
Programming - Keypad/display and PC
