HKC Connected Vape Sensor
Discreet Detection. Secure Connectivity. Installer‑Led Value.
The HKC Vape Sensor provides accurate detection of vaping and smoking in restrooms and sensitive areas. Plus as it's fully integrated with HKC intruder systems via an included RF transmitter it can be monitored via the SecureComm App.
Developed by HKC and TAKEX for professional installers and privacy‑sensitive environments.
Designed for Education & Commercial Environments
The HKC Vape Sensor helps organisations meet duty‑of‑care requirements while respecting privacy and supporting safer, healthier spaces without intrusive technology.
More Than a Device, a Fully Connected Service
When paired with SecureComm, the Vape Sensor enables:
- Remote alerts
- Managed detection services
- Scalable, long‑term customer value
A high‑sensitivity particle sensor identifies airborne particles associated with vaping and smoking, supported by adaptive algorithms that minimise false alarms.
Fully Integrated with HKC & SecureComm
Connects directly to HKC intruder systems via an included RF transmitter, with secure alerts and system visibility available via the SecureComm App.
Privacy‑Safe by Design
No cameras. No microphones. No recording, so it's ideal for schools and public spaces.
Key Features
- Detects vaping and smoking in restrooms and similar areas
- Adjustable sensitivity (Standard / Low)
- Configurable dry contact output (N.C. / N.O.)
- One‑shot or real‑time output modes
- Integrated local alarm buzzer
- Self‑diagnosis with fault indication
- Screwless terminals
- Tamper‑resistant cover
- Wall or ceiling mounting
Technical Specification
| Supply Voltage | 10.5V - 28V DC (non-polarity) |
| Current Consumption | 85mA max |
| Weight | 210g |
| Size | 137mm diameter x 41mm depth |
