| Model Number | NVR8 |
| Video Inputs | 8 |
| Video Compression | MJPEG / MPEG-4 / H.264 |
| Video Resolution | 5MP / HD / Megapixel / FD1 / CIF / QCIF |
| Maximum Frame Rate | 200FPS (1.3MP, H.264) |
| Audio Streaming | Two-Way Audio |
| Display Mode | Live View / Playback / Full Screen |
| Split Screen / Full Screen | 1 / 4 / 8 (Use Favourite Mode) |
| PTZ Support | Virtual PTZ / Auto Pan / Preset Point / Preset Sequence / Digital PTZ |
| Snapshot / AVI | Video Snapshot in JPEG Format / Export Playback Videos To PC in AVI Format |
| E-Map | Motion Detected Event Display on E-Map & Google Map |
| Mobile Phone View | Supports iPhone, Blackberry, Windows Mobile, Android & Symbian |
| Search Method | Time, Date, Event |
| Playback Controls | Play, Pause, Stop, Forward, Reverse, Speed Adjust, Frame By Frame |
| Recording Mode | Manual, Continuous, Scheduled, Event |
| Network Protocols | HTTP, SMTP, DHCP, ARP, NTP, DNS, UPnP, FTP |
| User Access | 7 (Administrator, Guest, User Defined) |
| Events | System Events – System Start, System Settings Modified, Camera Settings Modified, Start Recycle, Disk Full. Camera Events – Motion / Sensor Detection |
| CMS | Yes (Supports Maximum 256 Channels). CMS Features Intelligent Video Analytics, Image Enhancement, Flexible Video Screen Assignment, E-Map Monitoring, Two-Way Audio, 4 Channel Synchronised Playback, Smart Search, Multi-Monitor Management, Smart Motion Dete |
| HDD | Internal 2 x SATA HDD (Max. 2TB per Drive) |
| Connectors | USB x 2, RS485 x 1, DI x 8, DO x 4, Ethernet: Gigabit, Power Adapter Connector |
| CPU & Memory | ARM9 500Mhz, 128MB DDR RAM |
| System Requirements | CPU: Intel Core 2 Duo @ 2.4Ghz or Higher RAM: 1Gb or Above NETWORK: 100 Megabit Network Interface Minimum Software Requirements: Internet Explorer7 or Above |
| Supported Brands | Various, Please Request For A List |
| Power | AC 230V |
| Power Consumption | 4.74A |
| Operating Conditions | Temperature: 5°C ~ 45°C, Humidity: 90% RH |
| Dimensions (W x H x D) | 220 x 90 x 220 mm |
| Weight | 4.6 Kg |
